Fabrication machines. Supplied, installed, serviced.

Machinesthat hold±0.03 mm.

Fiber lasers, press brakes, 5-axis mills and industrial printers, installed, trained and serviced by one team. 1,400 of them are running in 30 countries.

Book a demo cut Compare specs
3D fiber laser cutting head firing onto a steel plate 3D bent steel pipe elbow 3D CNC milling machine cutting an orange block 3D printer building a yellow cube
LivePierce and cut
180.0° ANGLE

Fiber laser F123 × 1.5 m bed. Cuts 25 mm steel.

Four lines.One integrator.

We pick the machine for your parts, not the other way round. Every line comes installed, calibrated and with your operators trained on it.

01Laser cutting

Fiber laser F12

A 12 kW source on a 3 × 1.5 m shuttle bed. Mild steel up to 25 mm, clean edges, no rework.

3D fiber laser cutting head

12kW

Source power

3×1.5m

Bed size

25mm

Steel, max

02Sheet-metal bending

Press brake B220

220 tonnes over 3.1 metres with an 8-axis backgauge. Angle sensors correct every bend as it happens.

3D bent steel pipe elbow

220t

Bending force

3.1m

Bending length

±0.3°

Angle accuracy

03CNC milling

5-axis mill M5

Simultaneous 5-axis on a 24,000 rpm spindle with a 60-tool changer. One clamping, finished part.

3D CNC milling machine

24krpm

Spindle

5axes

Simultaneous

60tools

Changer

04Industrial printing

Print P-series

Metal and polymer 3D printing at 0.05 mm layers, plus 1.6 m large-format printers for signage and wraps.

3D printer building a cube

0.05mm

Layer height

4lasers

Metal 3D

1.6m

Large format

The numbers,side by side.

Specifications of the four FORMA machine lines
Tap a column
Key rating12 kW220 t24,000 rpm0.05 mm
Working area3,000 × 1,500 mm3,100 mm1,200 × 800 × 600 mm400 × 400 × 400 mm
Accuracy±0.03 mm±0.3°±0.005 mm±0.05 mm
Max material25 mmmild steel12 mmmild steel, full lengthAnymachinable metalTi, 316L, Alplus PA12 polymer
Axes3 + shuttle8-axis gauge5 simultaneous4 lasers
Footprint11.2 × 3.9 m4.2 × 2.1 m3.6 × 2.9 m2.8 × 1.2 m
Lead time10 weeks6 weeks14 weeks8 weeks
Lease from€3,796per month€1,657per month€4,142per month€1,302per month

Cuts whatyou cut.

  • Mild steel

    25mm

    Max thickness

  • Stainless

    20mm

    Max thickness

  • Aluminium

    15mm

    Max thickness

  • Acrylic

    30mm

    Max thickness

How a machine gets to your floor

From first callto first part.

  1. 01

    Consult

    Day 1

    An application engineer looks at your parts, volumes and floor plan.

  2. 02

    Demo cut

    Week 1

    We run your drawing on the machine and send you the part.

  3. 03

    Install

    Week 6 to 14

    Rigging, levelling, power and calibration by our own crew.

  4. 04

    Training

    5 days on site

    Operators and maintenance staff, on your parts, in your hall.

  5. 05

    Service

    24/7, for life

    Remote diagnosis, spare parts and engineers for as long as it runs.

3D globe

FORMA in numbers

  • 1,400

    InstalledMachines running in job shops, OEM plants and schools.

  • 30

    CountriesFrom Porto to Pune, with engineers based in 11 of them.

  • 98%

    UptimeAverage across the connected fleet over the last 12 months.

Lease it.Cut inmonth one.

Fixed monthly payments over 2 to 7 years. Service and training are included in every lease.

Machine

€6,523/month

Machine €385,000. Illustrative, 4.9% APR, subject to approval.

Service around the clock

3D headset with the number 24

One number for every machine we sell. A service engineer picks up, dials into the controller and usually fixes it from here.

  • 4h

    Remote diagnosis on every alarm, day or night.

  • 48h

    An engineer on site anywhere in the EU.

  • 12k

    Spare parts on the shelf, shipped the same day.

Send usyour part.

Send us a drawing and we run it on the machine you are looking at. The finished part is in your hands within 10 days, with cycle time and cost per piece.
